High-Definition Wireless Jib Arm Video Surveillance Camera
Product Features
- Long-distance wireless vehicle transmission up to over 800 meters (designed for 600 meters in open areas)
- Supports PAL / NTSC video formats
- Built-in 5.8G wireless transmitting and receiving module
- Equipped with automatic wireless frequency hopping function
- Power supply: DC 8-32V
- Damping design for ceiling mounting adaptation
- Compatible with rechargeable battery power supply for flexible and convenient use
- Waterproof and dustproof performance with IP68 protection rating
Model EV-1901W
Camera Parameters Image Sensor CMOS 1/2.8”
Lens Parameter 5~50±5%mm 30Optical Zoom
Effective Pixels 1920*1080/1280*720
Viewing Angle Range 50.6 º-7.5 º（Wide Angle - Telephoto）
Minimum Illumination 0.01Lux（F1.5,AGC ON) Color Mode
Video Format Video System Auto N/P Recognition Video Compression Standard H.264
Image Resolution (Main Stream) 1080p @ 30fps
Audio Function Not Supported Image Performance Maximum Image Size 1920x1080
Frame Rate 50Hz PAL 25fps；60Hz NTSC 30fps
Image Adjustment Hue, Contrast, Saturation, Sharpness Wireless Transmission Performance Working Frequency Band 5.180~5.835 GHz
Transmission Distance 800M(Open Environment)
Output Power 24dbm±1
Transmission Bandwidth 8MHz BER<1E-3
Video Latency Within 200ms
Others Operating Temperature -30℃--＋70℃
Storage Temperature -40~+80 ºC
Humidity 0% - 95%
Power Supply Voltage 12V~24V
Ingress Protection Rating IP68
Installation Method 吊装
Dimension 100mm(L)x106mm(W)x244mm(H)
