| Features: |
| 1. GC2053 Sensor Chip |
|
|
| 2. Low-Light Night Vision Lens |
|
|
| 3. AI recognition for vehicle and pedestrian detection, monitoring and warning alerts. |
|
|
| 4. Support built-in audio and external sound-light alarm. |
|
|
| 5. Built-in 12V power supply |
|
|
| 6. 103AI supports a maximum horizontal angle of 80° / 130AI supports a maximum horizontal angle of 110° |
|
|
| 7. Adopt Yizhi SV830D solution, integrated with 0.5T NPU, efficiently support intelligent algorithms such as human shape detection and vehicle detection. With professional ISP image quality, built-in 1 Gb DDR; support fast startup and image output. |
|
|
| Specifications: |
| No. |
Parameter Name |
Parameter Specification |
| 1 |
Sensor Type |
1/2.9" GC2053 CMOS + SV830D |
| 2 |
System Standard |
PAL/NTSC |
| 3 |
Effective Pixels |
1080P |
| 4 |
AI Recognition Algorithm |
Built-in algorithm on camera side; 0.5TOPS |
| 5 |
Minimum Illumination |
0.1LUX/F1.2 |
| 6 |
Definition |
AHD: 1.3MP 720P, 2MP 1080P, VGA pixel CVBS |
| 7 |
Scanning Frequency |
25Hz |
| 8 |
Gamma Value |
0.45 |
| 9 |
Electronic Shutter Speed |
1/50~1/100000s |
| 10 |
Signal-to-Noise Ratio |
>38dB |
| 11 |
Video Output |
Default AHD 1080P/PAL (1080P/720P/CVBS customizable, NTSC/PAL customizable) |
| 12 |
Waterproof Rating |
IP69K |
| 13 |
Anti-Vibration Rating |
4G |
| 14 |
Cable Interface |
Standard mini 4P aviation connector (green electronic wire is the alarm output trigger wire) |
| 15 |
Operating Voltage |
DC 12V |
| 16 |
Power Consumption |
1.4W ±10% |
| 17 |
Maximum Current |
12V/120mA |
| 18 |
Operating Temperature |
-20℃ ~ +70℃ |
| 19 |
Storage Temperature |
-30℃ ~ +80℃ |
