| Features: |
| 1. GC2053 sensor chip |
| 2. Low-light night vision lens |
| 3. AI recognition is suitable for monitoring and early warning of vehicles and pedestrians. |
| 4. Support built-in audio and external sound and light alarm. |
| 5. Support button adjustment of required functions and parameters |
| 6. Built-in 12V power supply |
| 7. 103AI supports a maximum horizontal angle of 80 degrees / 130AI supports a maximum horizontal angle of 110 degrees |
| 8. Adopt SmartSens SV830D solution, integrated with 0.5T NPU, which efficiently supports intelligent algorithms such as human detection and vehicle detection. It has professional ISP image quality, built-in 1 Gb DDR, and supports fast startup and image output. |
| |
|
|
| Specifications: |
| No. |
Parameter Name |
Parameter Specification |
| 1 |
Sensor Type |
1/2.9" GC2053 CMOS + SV830D |
| 2 |
System Standard |
PAL/NTSC |
| 3 |
Effective Pixels |
1080P |
| 4 |
AI Recognition Algorithm |
Built-in algorithm on camera side; 0.5TOPS |
| 5 |
Minimum Illumination |
0.1LUX/F1.2 |
| 6 |
Definition |
AHD: 1.3MP 720P, 2MP 1080P, VGA pixel CVBS |
| 7 |
Scanning Frequency |
25Hz |
| 8 |
Gamma Value |
0.45 |
| 9 |
Electronic Shutter Speed |
1/50~1/100000s |
| 10 |
Signal-to-Noise Ratio |
>38dB |
| 11 |
Installation |
Support front, rear, left and right installation (different rulers), and the corresponding mode can be set according to installation requirements |
| 12 |
Video Output |
Default AHD 1080P/PAL (1080P/720P/CVBS, NTSC/PAL, the required effect can be set by yourself) |
| 13 |
Mirror Image |
The required mirror image can be set according to installation requirements |
| 14 |
Flip |
Whether to flip can be set according to installation requirements |
| 15 |
Early Warning |
Pedestrian/vehicle warning, pedestrian warning, vehicle warning can be set by yourself |
| 16 |
Ruler |
The required ruler shape can be set by yourself |
| 17 |
Waterproof Level |
IP69K |
| 18 |
Anti-vibration Level |
4G |
| 19 |
Cable Interface |
Standard small 4P aviation connector (the green electronic wire is the alarm output trigger wire, and the 2P BMW connector is connected to the button box) |
| 20 |
Operating Voltage |
DC12V |
| 21 |
Power Consumption |
1.4W ±10% |
| 22 |
Maximum Current |
12V/120mA |
| 23 |
Operating Temperature |
-20℃ ~ +70℃ |
| 24 |
Storage Temperature |
-30℃ ~ +80℃ |
