| 2. Main Functions |
| 1. Support 4CH AHD AHD 720P/720N/1080P/1080N input. 1 channel DMS optional |
| 2. 3CH intelligent BSD blind zone alarm .The size of the range can be set. |
| 3. Intelligent voice-activated AI to switch the display screen. |
| 4. With ACC power-off memory, real-time save video. |
| 5.10.1 inch 1024*600 IPS BOE highlight screen. |
| 6. Brightness, saturation and contrast are adjustable. |
| 7. SD card supports up to 256G. |
| 8. Wide voltage power supply 12-24V. |
| 9. Front view with microphone recording. |
| 10. Mirror and none mirror are adjustable for each channel |
| 10. With speaker |
| 3. SPECS |
| Specification |
Model No：EV-1010MHQ-DVR |
| Screen ratio |
16:9 |
| Resolution |
1024*R.G.B*600 BOE |
| Back light |
LED, brightness 400 cd/m2 |
| Contrast |
500:1 |
| Viewing angle |
U—85°，D—85°，L—85°，R—85° |
| Operation method |
Full screen touch/button control |
| OSD control |
Time Setting, Brightness Adjustment, Intelligent Driving, Loop Recording, System Setting |
| Power consumption |
Normal working condition＜11.4W |
| Signal input |
Support AHD 720P/720N/1080P/1080N video signal input, mixed signal input is not supported |
| DMS |
Optional |
| Recording |
Support |
| SD card storage |
Support 8-256G , high-speed card |
| Video compression format |
H.264 compression mode |
| Video resolution |
1200*720 |
| Video playback |
Single channel playback |
| File format |
ST |
| File size |
About 7.24M/min (720/1080) |
| System language |
Chinese, English, Japanese, Korean |
| Display image switch |
Voice control, double-tap touch screen, button switch |
| Trigger |
4CH, with guideline function |
| Blind Spot Detection |
Support 3 channel, Left, right, back |
| Shockproof level |
4G |
| Audio |
Front view recording |
| Working temperature |
-20~+70 ºC |
| Storage temperature |
-30~+80 ºC |
| Working humidity |
85%RH |
| Power supply |
12-24V |
| Booting time |
5S |
| Current consumption |
TYPE:12V/900MA（4 channel） |
| Speaker |
With speaker |
