| Product Features |
| • 2.4G WIFI wireless transmission with 5DB high-gain antenna |
| • APP WIFI wireless camera, compatible with Android and iOS mobile phones |
| • Support HD LED night vision function |
| • IP67 waterproof rating |
| • Transmission distance: 50M in open area, 5-10M for container trucks |
| • Horizontal viewing angle: more than 100° both left and right |
| • DC5.5 female port for 12V DC charging, with reverse connection and overvoltage protection |
| • Battery level indicator with red light prompt for low battery |
| • Wireless installation with built-in battery, working time up to 16 hours |
| • Support charging while using without performance impact |
| • Anti-slip magnet design, load capacity up to 3KG |
| |
|
| Technical Specifications |
| Parameter |
Specification |
| Model |
EV-111WHD |
| Resolution |
1920*1080 (2 Megapixels) |
| Image Sensor |
1/3” CMOS |
| Viewing Angle |
100 Degrees |
| Transmission Distance |
50M (Open Area) |
| Transmission Bandwidth |
20Mbps (Max) |
| Battery Capacity |
4400mAh |
| Battery Level Indicator |
Green light when powered on, red light when charging |
| Operating Voltage / Charging Time |
5V / 2 Hours |
| Working Time |
12 Hours |
| Camera Adjustable Angle |
0-90° |
| AI Function |
Human and Vehicle Detection |
| Power On/Off Method |
Long press to power on/off |
| Installation Method |
Magnet base adsorption installation |
| Reverse Parking Guide Line |
Customizable adjustment |
| Night Vision Effect |
Full-color white light |
| Signal-to-Noise Ratio (SNR) |
46.5dB |
| Waterproof Rating |
IP67 |
| Transmission Sensitivity |
-89 dBm |
| Material |
Black Aluminum Alloy |
| Shock Resistance Level |
4G |
| Power Cable |
USB male to DC5.5 male cable |
| Operating Temperature |
–20℃ ~ 70℃, RH95% MAX |
| Storage Temperature |
–30℃ ~ 85℃, RH95% MAX |
| Dimensions |
74*45.5*56.5mm |
| Accessories |
5.5DC male power cable, power adapter, car charger power cable, 3DB antenna |
