| No. |
Item |
Specification |
| 1 |
Image Sensor |
1/4" CMOS |
| 2 |
Effective Pixels |
1280(H) × 720(V) |
| 3 |
White Balance |
Auto (White light) |
| 4 |
Backlight Compensation |
Supported |
| 5 |
Noise Reduction |
2D DNR |
| 6 |
Viewing Angle |
2.1mm waterproof lens, mirror image, horizontal viewing angle 120° |
| 7 |
S/N Ratio |
≥52dB (AGC OFF) |
| 8 |
Video System |
PAL standard (NTSC optional) |
| 9 |
Audio |
Not supported |
| 10 |
Distance Grid |
Not included by default (customizable) |
| 11 |
Video Output |
1-CH HD signal output, 1.0Vp-p / 75Ω |
| 12 |
Gamma Correction |
0.45 |
| 13 |
Waterproof Grade |
IP68 |
| 14 |
Shockproof Grade |
4G |
| 15 |
Connector |
Standard aviation connector |
| 16 |
Operating Voltage |
DC 9–12V |
| 17 |
Power Consumption |
Approx. 1.5W |
| 18 |
Max. Current |
130mA |
| 19 |
Operating Temperature |
-40℃ to +70℃ |
| 20 |
Storage Temperature |
-40℃ to +80℃ |
