| SPECS |
Model No.:EV-9010MHQ |
| Aspect Ratio |
16：9 |
| Resolution |
1024*R.G.B.*600 |
| Backlight |
LED, Luminance: 300cd/m² |
| Contrast |
500：1 |
| Recording Speed |
1080P: 25f/s/D1:25f/s |
| Viewing Angle |
UP-60°，DOWN-70°, LEFT-60°, RIGHT-70° |
| Working Temperature |
-20~+60 ºC |
| Working Humidity |
85%RH |
| Storage Temperature |
-30~+85 ºC |
| Power Supply |
DC 9-30V |
| Boot Time |
20S |
| Current |
750mA |
| OSD Control |
Image Setting, Mirror Setting, System Setting |
| Power Consumption |
<9W |
| Signal input |
4 channel 1080P/CVBS video input |
| Image Display |
Multiple image display switchable |
| Trigger Control |
4 channel reversing trigger control, with parking guide line function |
| System |
PAL/NTSC |
| Shockproof Level |
4G |
| Audio |
1 channel audio input (CH1 playback with audio) |
| Speaker Output Consumption |
32Ω2W |
| Weight |
? |
| Size |
? |
