1080P Side View Backup Camera
1. Mini Aluminum Shell
2. Super HD Camera: 1080P/720P
3. IP69K waterproof IP rate
4. Waterproof and weather resistant housing for outdoor use
5. Excellent night vision
6. Infrared LED light: 18
7. Mirror / Normal image switch
8. Power supply: 9V ~ 12V/ 24V
9. Aluminum alloy material shell, outside hanging design; Suitable for bus, trucks and special vehicles
| No. | Item | Specification |
| 1 | Image Sensor | 1/3 Inch CMOS SC2315 |
| 2 | Effective Pixels | 1920(H) × 1080(V) |
| 3 | White Balance | Auto (No light required) |
| 4 | Backlight Compensation | Supported |
| 5 | Noise Reduction | 3D DNR |
| 6 | Viewing Angle | 2.1mm waterproof lens, mirror image, horizontal viewing angle 180° |
| 7 | S/N Ratio | ≥52dB (AGC OFF) |
| 8 | Video System | PAL standard (NTSC optional) |
| 9 | Audio | Not built-in (optional) |
| 10 | Distance Grid | Not built-in (switchable via wire control) |
| 11 | Mirror Image | Default mirror (switchable via wire control) |
| 12 | Video Output | 1-CH HD signal output, 1.0Vp‑p / 75Ω |
| 13 | 3D Noise Reduction | Supported |
| 14 | Waterproof Grade | IP68 |
| 15 | Shockproof Grade | 4G |
| 16 | Connector | Standard aviation connector |
| 17 | Operating Voltage | DC 9–12V (24V optional) |
| 18 | Power Consumption | Approx. 1.5W |
| 19 | Max. Current | 155mA (5V) |
| 20 | Operating Temperature | -40℃ to +70℃ |
| 21 | Storage Temperature | -40℃ to +80℃ |
