| High Resolution Rear View Camera |
| SPECS |
Model No.：EV-122HD |
| Image sensor |
CMOS 1/4 |
| Resolution |
720P/100W |
| Illuminance |
0.1Lux，infrared night vision |
| Viewing angle |
2.1mm waterproof lens 130 degree |
| Image |
Mirror as default (Could set mirror&non-mirror switchable) |
| System |
PAL system as default (Could set PAL&NTSC switchable) |
| Audio |
Without audio as default (With audio optional) |
Distance grid
( reverse linne) |
Without distance grid (Could set with distance grid or without switchable) |
| Appearance |
Aluminium alloy material, out-standing design, suitable for bus, truck and small vehicles |
| Waterproof level |
IP68 |
| Shockproof level |
4G |
| Connectors |
4PIN or RCA |
| Power supply |
DC12-24V |
| Power consumption |
About 1.5W |
| Maximum current |
130MA |
| Output |
1 channel HD output |
| Working temperature |
-20℃ to 70℃ |
| Storage temperature |
-30℃ to 80℃ |
| Size |
67*55*43.5mm |
| Weight |
kg |
| Accessories |
Extension cable, DC 5.5 male connector extension cable, hexagon screws, bracket, user manual |
