| Specification |
Model No：EV-1010MHQ-4G |
| Screen ratio |
16:9 |
| Resolution |
1024*R.G.B*600 BOE |
| Back light |
LED, brightness 400 cd/m2 |
| Contrast |
500:1 |
| Viewing angle |
U—85°，D—85°，L—85°，R—85° |
| Operation method |
Full screen touch/button control |
| OSD control |
Time Setting, Brightness Adjustment, Intelligent Driving, Loop Recording, System Setting |
| Power consumption |
Normal working condition＜11.4W |
| Signal input |
Support AHD 720P/720N/1080P/1080N video signal input, mixed signal input is not supported |
| DMS |
Optional |
| Recording |
Support |
| SD card storage |
Support 8-256G , high-speed card |
| Video compression format |
H.264 compression mode |
| Video resolution |
1200*720 |
| Video playback |
Single channel playback |
| File format |
ST |
| File size |
About 7.24M/min (720/1080) |
| System language |
Chinese, English, Japanese, Korean |
| Display image switch |
Voice control, double-tap touch screen, button switch |
| Trigger |
4CH, with guideline function |
| Blind Spot Detection |
Support 3 channel, Left, right, back |
| Shockproof level |
4G |
| Audio |
Front view recording |
| Working temperature |
-20~+70 ºC |
| Storage temperature |
-30~+80 ºC |
| Working humidity |
85%RH |
| Power supply |
12-24V |
| Booting time |
5S |
| Current consumption |
TYPE:12V/900MA（4 channel） |
| Speaker |
With speaker |
